Connects2 CAM-1

The CAM-1 is a universal flush-mounted reversing camera that fits most cars and vans. Featuring a 1/3" (8.5mm) CCD, 580 TV lines and a resolution of 762×504. The CAM-1 has a viewing angle of 150 degrees and requires minimal lighting to operate. The CAM-1 is also IP67 rated, meaning it is protected against all common weather conditions and will continue to operate in temperatures from -30 degrees C to +65 degrees C.

Product specifications:
Sensor: 1/3" (8.5mm) CCD
Current consumption: 41mA @ 13.8V
TV lines: 580
Minimum illumination: 0.01 Lux
Angle: 150 degrees
Resolution: 762x504
TV system: NTSC
Video output: 1.0V pp 75ohm
Parking lines: No
Working voltage: DC 9-16V (negative ground)
Operating temperature: -30 degrees C to +65 degrees C
Waterproof rating: IP67
Infrared LEDs: No
Improved low-light performance: Yes
